Small-angle X-ray Scattering Beamline BL4C SAXS at Pohang Light Source II

• 발행기관: 한국구조생물학회
• 저자명: Kwang-Woo Kim Jehan Kim Young Duck Yun Hyungju Ahn Byoungseok Min Na Hyung Kim Seungyu Rah Hyo-Yun
• 간행물 정보: 『Biodesign』Vol 5, No 1, Mar, 24~29쪽, 전체 6쪽
• 주제분류: 자연과학 > 생물학
• 파일형태: PDF
• 발행일자: 2017.03.30

영문 초록

BL4C SAXS at the Pohang Light Source II is a small-angle X-ray scattering beamline based on an in-vacuum undulator insertion device, Si(111) DCM, and toroidal focusing mirror. The beamline normally provides high-flux synchrotron radiation X-ray sources with energies from 10.3 to 20.6 keV and a 100 µm (vertical) × 300 µm (horizontal) full width at half-maximum focal spot. The analysis of the SAXS data would be facilitated by means of useful ancillary equipment. The design of the beamline, the key components, and its role are described.

목차

INTRODUCTION

BEAMLINE OVERVIEW

SAMPLE STAGE

BEAMLINE SOFTWARE

BEAMLINE EQUIPMENT

CONCLUSIONS
