Extruded Cables for High-Voltage Direct-Current Transmission

Giovanni Mazzanti 지음

Wiley-IEEE Press 2013년 06월 07일 출간

작품소개

책소개

The only book on the market that provides current, necessary, and comprehensive technical knowledge of extruded cables and high#45;voltage direct#45;current transmissionThis is the first book to fully address the technical aspects of high#45;voltage direct#45;current (HVDC) link projects with extruded cables. It covers design and engineering techniques for cable lines, insulation materials, and accessories, as well as cable performance and life span and reliability issues.Beginning with a discussion on the fundamentals of HVDC cable transmission theory, Extruded Cables for High#45;Voltage Direct#45;Current Transmission: Advances in Research and Development covers:Both the cable and the accessories (joints and terminations), each of which affects cable line performanceThe basic designs of HVDC cables#151;including a comparison of mass insulated non#45;draining cables with extruded HVDC cablesThe theoretical elements on which the design of HVDC cables is based#151;highlighting the differences between HVAC and HVDC cablesSpace charge#45;related problems that have a critical impact on extruded insulation for HVDC applicationRecent advances in extruded compounds for HVDC cables such as additives and nano#45;fillersThe improved design of extruded HVDC cable systems#151;with emphasis on design aspects relevant to accessoriesCable line reliability problems and the impact on cable system designIncluding more than 200 illustrations, Extruded Cables for High#45;Voltage Direct#45;Current Transmission fills a gap in the field, providing power cable engineers with complete, up#45;to#45;date guidance on HVDC cable lines with extruded insulation.

목차

FOREWORD xiACKNOWLEDGMENTS xvLIST OF SYMBOLS AND ACRONYMS xviiINTRODUCTION xxvii1 INTRODUCTION 12 FUNDAMENTALS OF HVDC CABLE TRANSMISSION 112.1 Historical Evolution of HVDC Power Transmission 112.2 Economic Comparison Between HVAC and HVDC Transmission Systems 182.3 Configurations and Operating Modes of HVDC Transmission Systems 202.4 CSC and VSC Converters 232.4.1 Operation of a Line-Commutated Current Source Converter (LCC-CSC) 232.4.2 Operation of a Self-Commutated Voltage Source Converter (VSC) 252.4.3 CSC versus VSC: How Do They Affect Cable Insulation? 272.5 Cables for HVDC Transmission 272.5.1 Underground and Undersea Cable Transmission 272.5.2 Different HVDC Cable Types 292.5.2.1 Mass-Impregnated Nondraining (MIND) Cables 312.5.2.2 Oil-Filled (OF) Cables 322.5.2.3 Polypropylene Paper Laminate (known under a few different acronyms, i.e., PPL, MI-PPL, PPLP) or Lapped Thin-Film Insulated Cable 332.5.2.4 Polymer-Insulated or Extruded-Insulation Cable 332.5.3 HVDC Cable Insulation 362.5.3.1 Oil&n-Paper (or Lapped) Insulation 372.5.3.2 Extruded Insulation 373 MAIN PRINCIPLES OF HVDC EXTRUDED CABLE DESIGN 413.1 Differences Between HVAC and HVDC Extruded Cables 423.1.1 Differences in the Structure 423.1.2 Typical Formations of HVDC Extruded Cables 423.1.2.1 Conductor 423.1.2.2 Inner Semiconductive Layer 433.1.2.3 Insulation Layer 443.1.2.4 Outer Semiconductive Layer 443.1.2.5 Metallic Screen 453.1.2.6 Water Sealing (or Blocking) Systems 463.1.2.7 Protective Thermoplastic Sheath 473.1.2.8 Armoring 473.1.2.9 Jacketing (or External Sheath) 483.1.3 Differences in the Electric Field Distribution 483.1.3.1 Electric Field Distribution Within the Insulation of an HVAC Cable 483.1.3.2 S

출판사 서평

“The authors have done a great job, presenting a blend of experimental results to reinforce the theory and showing how to apply the theory to practical designs.”& (IEEE Electrical Insulation Magazine, 1 January 2014)

작가정보

저자(글) Giovanni Mazzanti

저자 :

저자 :

저자 :

저자 :

저자 :
저자 :
저자 :
GIOVANNI MAZZANTI, PhD, is an Associate Professor at the University of Bologna where he teaches high#45;voltage engineering and power quality. He is an active researcher in the field of power engineering and has published more than seventy peer#45;reviewed papers and articles. He is a member of IEEE#45;PES and IEEE#45;DEIS. Since October 2012, he has chaired the new IEEE#45;DEIS Technical Committee on HVDC cable systems.MASSIMO MARZINOTTO, PhD, works at Terna (the Italian TSO) in the HDVC systems area dealing with cables, insulators, surge arresters, insulation coordination, HVDC converters, and HVDC electrodes. He is a member of IEEE#45;DEIS, IEEE#45;PES and CIGRE, a Senior Member of the IEEE, and is active in various IEEE and CIGRE working groups and committees. He is also author or coauthor of several publications on IEEE transactions and conferences.
